If you need to buy more, please click: /products/15427/smd_2835 waterproof_ led_module 3_led_chips_with_optical_lens 0_72w_l70_x_w16_x_h7mm_designed_for_internal_illumination_of_signs.html
Description:Target at the middle and end light sources used on identification;adopting the chips manufactured by famous big factories, high brightness,large emitting angle,low thermal resistance, and low light decay,high uniformity of the emitting color,using pure thick copper wire and designing by low thermal resistance to ensure the steady current and lower the heat; reasonable circuit design, convenient to install and wiring regulation, life span over 30000 hours, power supply at constant 12V DC; safety, energy saving and eco-friendly. High power 2835SMD LEDs 3 LED Chips with Optical Lens, 170 Degree, beam pattern, Double sided adhesive foam tape, 3 inch wires between each module. Two modules per foot.
Specification:
| Basic parameters |
| Color |
White, Red, Blue, Green
|
LED type |
2835 |
| LED Qty |
3PCS
|
Dimension |
(70 x 16 x7mm) |
| Module interface |
2 x 3.2 " (2 x80mm) RVleads |
Interface definition |
Gray anode, white cathode |
| Cluster Qty |
20pcs |
Module space between |
80mm |
| Weight |
0.4oz (10g)±5% |
Lifespan |
MTBF>30000hours |
| Environment parameters |
| Working temperature |
-40°C∼60°C |
| Defend grade |
IP65 competely satisfies the outdoor lighting standard |
| Electronic specifications |
| Working input voltage |
D12V±5% |
Max power |
0.72 W |
| Driving mode |
Invariable voltage! (Insure every LED working under the invariable voltage) |
| Lighting capability |
| Luminous flux |
65 lm |
| Beam angle |
170° |
| |
SMD3528 |
SMD2835 |
SMD5050 |
| Luminous Flux |
7 - 8LM |
20 -22LM |
21 -24LM |
| Power |
0.1W |
0.22W |
0.24W |
| Price |
Low |
Middle |
High |
| Difference |
Power Saving. Economical. |
Super Brightness. Low Lumens Depreciation. |
High Performance / Price Ratio (Economical / Super Brightness / Long Lifespan) |
| Usage |
You need spend about $22 to make this lighting Channel Letter, cheap and power saving, but has low brightness. |
You need spend about $27 to make this lighting channel letter, power saving and with high brightness. |
You need spend about $36 to make this lighting channel letter, with super high brightness. |
About luminouse efficiency, comppare with SMD3528,SMD5050 and SMD2835. The SMD3528 is low, SMD5050 in the middle and the SMD2835 is high. But for the price, SMD2835 in the middle, SMD3528 is low and the SMD5050 is high.
1. LED Module used for light box making:
2. LED module used for Sign Cabinets:
3. LED module used for signage making:
4. LED module used for channel leter:
5. LED module used for Edge Lit Signs:
